71M6515H Demo Board User’s Manual
Real-Time Monitor Area (11):
This area consists of four entry fields to the right of the System Constants area. The entries determine any
four CE data memory locations to be monitored. The RTM_ENABLE square button in the Configuration area
has to be in the “1” position for the RTM to be active.
GUI Element
(Label)
RTM0
RTM1
RTM2
RTM3
Default
0x00
0x00
0x00
0x00
Function
First CE data memory location to be monitored.
Second CE data memory location to be monitored.
Third CE data memory location to be monitored.
Fourth CE data memory location to be monitored.
Note: Using the RTM interface requires special external hardware. Contact TERIDIAN for details.
QUANT Area (12):
This area consists of three entry fields that can be used to eliminate non-linearity at low currents caused by
truncation noise. The parameters entered here are closely related to the calibration parameters.
GUI Element
(Label)
Watt
VAR
I
Default
0
0
0
Function
Noise compensation factor for the Watt calculation
Noise compensation factor for the VAR calculation
Noise compensation factor for the current calculation
Multi-Purpose Area (13):
This area consists of two list fields and three rectangular buttons.
GUI Element
(Label)
SCALED/RAW
STANDARD/
HEX
Refresh
Apply
CLEAR
Revision 2.0
Element
Type
List field
List field
Rectangular
button
Rectangular
button
Rectangular
button
Function
This list field toggles the display of display and entry fields between
scaled (displayed values scaled using IMAX and VMAX) and raw
data (raw counts from 6515H) mode. In scaled mode, values for
voltage, current, and energy will be displayed as V, A, Wh, VARh etc.
In raw mode, the values will appear in the internal format of the
71M6515H chip.
This list field toggles the values shown in display and entry fields
between standard (decimal) and hexadecimal mode.
Pressing this button forces the GUI to transmit any changes made in
entry or list fields to the 71M6515H chip.
Placing the cursor into another entry field will have the same effect as
the Refresh button. Pressing this button will apply a change made in
an entry field.
Pressing this button will clear the contents of the Status Window.
19 of 66
? Copyright 2005 TERIDIAN Semiconductor Corporation
